| Place of Origin | China |
| Brand Name | waterun |
| Certification | CE |
| Model Number | No (W00465) |
Electronic Text equitment digital bottle cap torque meter torque measuring device
Description:
It is used to test the tightness of bottle cap, wrenches, screwdrivers and other fasteners, bottle cap locking of bottled packaging products, suction nozzle packaging products, opening torque value, or anti-torsion performance of some parts , such as toys and hardware plastic products. It can be used in three torque units , such as kgf • cm, N • m, lBf •in .
Handling Precaution
Do not apply a torque above the maximum allowable load or damage will result. Do not tap on or apply a load to the acrylic display panel. Make zero adjustment to the strain gauge regularly while using the Torque Tester. The gauge is very sensitive to environmental conditions.
Avoid using the Tester in the following places:
1. Where water, oil or other liquid may splash
2. Where vibrations may occur and where dust or hot air may be emitted
3. Outdoors or where there are electric noises
4. In humidity (appropriate humidity of 35%-65%)
5. In high temperatures (appropriate temperature of 15-40 centigrade.)
6. Where the environmental conditions may cause functional failure or degrade performance
Product Parameters:
| Model | HP-10 | HP-50 | HP-100 | |
|
Measurement range
|
Kgf.cm | 0.15-10.00 | 0.75-50 | 1.5-100 |
| N.m | 0.015-1.0 | 0.075-5 | 0.15-10 | |
| Lbf.in | 0.19-9.00 | 0.75-45 | 1.5-90 | |
| Accuracy | Within ± 0.5% | |||
| Applicable cap diameter | 16-160mm | |||
Applications:
1. Specially designed for measuring and calibrating the torque of bottle caps.
2. The clamp is easy to install and adjust. It can hold caps of different shapes and different dimensions.
Product Features:
1. High precision, high resolution, quick sampling speed, full-screen display.
2. Adopting high precision torque sensor, with torque direction display.
3. Upper and lower limit value setting, red and green indicating lights and buzzer audible and visual alarm.
4. Three units can be switched each other (N·m,Kgf·cm,Lb·in).
5. Real-time, peak, automatic peak three models of optional switch.
